Product Details
Battery System: Cabinet
Battery Type: N/A
Bypass Amps Max: 222.0
Bypass Voltage: 208
Bypass Wiring: 4 wire
Condition: Used
Configuration (CTO): TB081130003310
DC Amps: 126
DC Bus Voltage: 384-480
Height (Inches): 74.0
Input Amperage Max: 240.0
Input Frequency: 60 Hz
Input Voltage: 208
Input Wiring: 3 wire
Internal Battery Size: N/A
kVA: 80
kW: 72.0
Length/Depth (Inches): 32.0
Maintenance Bypass: Yes
Model: 9390-80
Model Family: 9390
Output Amps Max: 222.0
Output Frequency: 60 Hz
Output Voltage: 208
Output Wiring: 4 wire
Phase: 3 Phase
Serial Number: EA214CBA02
Shipping Info Misc: 35x 40x 79
SKU: 6794
UPS Input: Single
Weight (Lbs) : 950.0
Width (inches): 27.0
Year: 2007
